Gallery
Description:
- Wood Truss System: Gable Style 4′ Center 4 / 12 Pitch 1′ Overhang engineered trusses
- 10′ o/c 6×6 Treated Post load bearing columns
- Girt Material 2×4, Girt Spacing 2′
- Purlin Material 2×4, Purlin Spacing 2′
- Single bubble reflective insulation on Roof & Walls
- Siding: Panel-Loc Plus 29ga 40yr. Painted Steel :: Gray Color: 40yr Rust Warranty / 30yr Chalk & Fade Warranty
- Roofing: Panel-Loc Plus 29ga 40yr. Painted Steel :: Charcoal Color: 40yr Rust Warranty / 30yr Chalk & Fade Warranty
- Trim Color: Trim Color = Charcoal
- 1′ Overhang on 2—Eaves & 2—Gables
- 1668 Sq.Ft. of Concrete 4″ Slab 4,000 PSI (Vapor Barrier & Wire Reinforced)
- Door and Window List:
2 – 16′ x 10′ Insulated Garage Door (Opener Prepped)
– Color–White
1 – 3′ 6-Panel Steel Door NeverRot Jamb Right Hand
4 – 3’X4′ Single Hung Vinyl Insulated Windows
